Maximum operating height
14m
Maximum platform height
12m
Platform extension size
0.9m
Length (without ladder)
2.27(2.48)m
Width - collapsed
1.22m
Overall height (guardrail folded)
2.64(1.96)m
Platform size (length x width x height)
2.27*1.12*1.12m
Ground clearance: large/small
110/19mm
Wheelbase
1.87m
Maximum number of people allowed to work: indoors/outdoors
2/0
Rated load
350kg
Extended platform rated load
120kg
Travel speed: folding/lifting
3.5/0.8
Gradeability
25%
Lifting motor
3.5kW
Turning radius: inside/outside
0.4/2.4
Allowable inclination angle during operation: left/right/inside/outside
1.5/3°
tire
381*127mm
battery capacity
260Ah
battery voltage
4*6v
Walking style
Front drive/hydraulic drive
Charger input voltage
AC100-240v
Charger output current
36
Machine quality
3100kg
Forklift hole
Backward/Sideways
standard
GB25849
